TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-17 Port 30 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

AK22 P30.3

GTM_TIM7_IN3_6

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 3 of TIM module 7

Mux input channel 3 of TIM module 4

Data Bus Input

GTM_TIM4_IN3_10

EBU_AD_IN15

P30.3

General-purpose output

GTM muxed output

Reserved

GTM_TOUT193

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD15

Data Bus Output

General-purpose input

Mux input channel 4 of TIM module 7

Mux input channel 4 of TIM module 4

Data Bus Input

AJ23 P30.4

FAST /

PU1 /

VEBU /

GTM_TIM7_IN4_5

GTM_TIM4_IN4_9

EBU_AD_IN8

P30.4

General-purpose output

GTM muxed output

Reserved

GTM_TOUT194

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD8

Data Bus Output

Data Sheet

126

V 1.2, 2021-03
