TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-17 Port 30 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

AK23 P30.5

GTM_TIM7_IN5_5

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 5 of TIM module 7

Mux input channel 5 of TIM module 4

Data Bus Input

GTM_TIM4_IN5_9

EBU_AD_IN13

P30.5

General-purpose output

GTM muxed output

Reserved

GTM_TOUT195

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD13

Data Bus Output

General-purpose input

Mux input channel 6 of TIM module 7

Mux input channel 6 of TIM module 4

Data Bus Input

AJ24 P30.6

FAST /

PU1 /

VEBU /

GTM_TIM7_IN6_5

GTM_TIM4_IN6_9

EBU_AD_IN4

P30.6

General-purpose output

GTM muxed output

Reserved

GTM_TOUT196

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD4

Data Bus Output

Data Sheet

127

V 1.2, 2021-03

OPEN MARKET VERSION
