TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-15 Port 25 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

AB30 P25.11

GTM_TIM7_IN3_5

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 3 of TIM module 7

Mux input channel 3 of TIM module 4

General-purpose output

GTM muxed output

Reserved

GTM_TIM4_IN3_9

P25.11

GTM_TOUT217

—

Reserved

—

Reserved

EBU_A20

—

Address Output

Reserved

—

Reserved

EBU_BC3

Byte Control

AA29 P25.12

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 4 of TIM module 7

Mux input channel 4 of TIM module 4

General-purpose output

GTM muxed output

Reserved

GTM_TIM7_IN4_4

GTM_TIM4_IN4_8

P25.12

GTM_TOUT218

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_A19

Address Output

AA30 P25.13

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 5 of TIM module 7

Mux input channel 5 of TIM module 4

General-purpose output

GTM muxed output

Reserved

GTM_TIM7_IN5_4

GTM_TIM4_IN5_8

P25.13

GTM_TOUT219

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_A17

Address Output

Data Sheet

122

V 1.2, 2021-03

OPEN MARKET VERSION
