TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-14 Port 24 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

K30

P24.15

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 7 of TIM module 7

Mux input channel 7 of TIM module 5

Address Input

GTM_TIM7_IN7_2

GTM_TIM5_IN7_5

EBU_A_IN7

P24.15

General-purpose output

GTM muxed output

Reserved

GTM_TOUT237

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_A7

Address Output

Table 2-15 Port 25 Functions

Ball Symbol

Ctrl. Buffer

Type

Function

AG30 P25.0

GTM_TIM6_IN0_7

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 0 of TIM module 6

Mux input channel 0 of TIM module 3

General-purpose output

GTM muxed output

Reserved

GTM_TIM3_IN0_12

P25.0

GTM_TOUT206

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_BFCLKO

Burst Flash Clock Output

Data Sheet

117

V 1.2, 2021-03

OPEN MARKET VERSION
