TC1767
Pinning
Table 4
Pin Definitions and Functions (PG-LQFP-176-5 Package1)) (cont’d)
Ctrl. Type Function
Pin Symbol
127 P3.6
SLSO01
I/O0 A2/
Port 3 General Purpose I/O Line 6
PU
O1
SSC0 Slave Select Output 1
SSC1 Slave Select Output 1
SSC0 AND SSC1 Slave Select Output 1
Port 3 General Purpose I/O Line 7
SSC0 Slave Select Input 1
SSC0 Slave Select Output 2
SSC1 Slave Select Output 2
GPTA0 Output 89
SLSO11
O2
SLSOANDO1 O3
131 P3.7
SLSI01
I/O0 A2/
PU
I
SLSO02
SLSO12
OUT89
O1
O2
O3
128 P3.8
I/O0 A2/
Port 3 General Purpose I/O Line 8
SSC0 Slave Select Output 6
ASC1 Transmit Output
GPTA0 Output 90
PU
SLSO06
TXD1
O1
O2
OUT90
O3
138 P3.9
I/O0 A1/
Port 3 General Purpose I/O Line 9
ASC1 Receiver Input A
ASC1 Receiver Output A (Synchronous Mode)
ASC1 Receiver Output A (Synchronous Mode)
GPTA0 Output 91
PU
RXD1A
RXD1A
I
O1
RXD1A
O2
OUT91
O3
137 P3.10
REQ0
I/O0 A1/
Port 3 General Purpose I/O Line 10
External Request Input 0
-
PU
I
Reserved
Reserved
OUT92
O1
O2
-
O3
GPTA0 Output 92
144 P3.11
REQ1
I/O0 A1/
Port 3 General Purpose I/O Line 11
External Request Input 1
-
PU
I
Reserved
Reserved
OUT93
O1
O2
O3
-
GPTA0 Output 93
Data Sheet
65
V1.3, 2009-09
