TC1767
Pinning
Table 4
Pin Symbol
136 P3.0
RXD0A
Pin Definitions and Functions (PG-LQFP-176-5 Package1)) (cont’d)
Ctrl. Type Function
I/O0 A1/
Port 3 General Purpose I/O Line 0
PU
I
ASC0 Receiver Input A (Async. & Sync. Mode)
ASC0 Output (Sync. Mode)
RXD0A
O1
RXD0A
O2
ASC0 Output (Sync. Mode)
OUT84
O3
GPTA0 Output 84
135 P3.1
TXD0
I/O0 A1/
Port 3 General Purpose I/O Line 1
ASC0 Output
PU
O1
TXD0
O2
ASC0 Output
OUT85
O3
GPTA0 Output 85
129 P3.2
SCLK0
I/O0 A2/
Port 3 General Purpose I/O Line 2
SSC0 Clock Input (Slave Mode)
SSC0 Clock Output (Master Mode)
SSC0 Clock Input (Master Mode)
GPTA0 Output 86
PU
I
SCLK0
O1
SCLK0
O2
OUT86
O3
130 P3.3
MRST0
MRST0
MRST0
OUT87
I/O0 A2/
Port 3 General Purpose I/O Line 3
SSC0 Master Receive Input (Master Mode)
SSC0 Slave Transmit Output (Slave Mode)
SSC0 Slave Transmit Output (Slave Mode)
GPTA0 Output 87
PU
I
O1
O2
O3
132 P3.4
MTSR0
MTSR0
MTSR0
OUT88
I/O0 A2/
Port 3 General Purpose I/O Line 4
SSC0 Slave Receive Input (Slave Mode)
SSC0 Master Transmit Output (Master Mode)
SSC0 Master Transmit Output (Master Mode)
GPTA0 Output 88
PU
I
O1
O2
O3
126 P3.5
SLSO00
SLSO10
I/O0 A2/
Port 3 General Purpose I/O Line 5
SSC0 Slave Select Output 0
PU
O1
O2
SSC1 Slave Select Output 0
SLSOANDO0 O3
SSC0 AND SSC1 Slave Select Output 0
Data Sheet
64
V1.3, 2009-09
