TC1767
Introduction
2.4.6
General Purpose Timer Array (GPTA)
The TC1767 contains the General Purpose Timer Array (GPTA0). Figure 11 shows a
global view of the GPTA module.
The GPTA provides a set of timer, compare, and capture functionalities that can be
flexibly combined to form signal measurement and signal generation units. They are
optimized for tasks typical of engine, gearbox, and electrical motor control applications,
but can also be used to generate simple and complex signal waveforms required for
other industrial applications.
GPTA0
Clock Generation Cells
FPC0
DCM0
FPC1 PDL0
DCM1
FPC2
DIGITAL
PLL
FPC3
DCM2
DCM3
FPC4 PDL1
FPC5
fGPTA Clock Distribution Cells
Clock
Conn.
Signal
Generation Cells
GT0
GT1
LTCA2
GTC00
GTC01
GTC02
GTC03
LTC00
LTC01
LTC02
LTC03
LTC00
LTC01
LTC02
LTC03
Global
Timer
Cell Array
Local
Timer
Cell Array
Local
Timer
Cell Array
GTC30
GTC31
LTC62
LTC63
LTC30
LTC31
I/O Line
Sharing Block
I/O Line Sharing Block
Interrupt Sharing Block
Interrupt
Sharing Block
MCB05910_TC1767_LTC32
Figure 11
General Block Diagram of the GPTA Modules in the TC1767
Data Sheet
41
V1.3, 2009-09
