TC1767
Introduction
2
Introduction
This Data Sheet describes the Infineon TC1767, a 32-bit microcontroller DSP, based on
the Infineon TriCore Architecture.
2.1
About this Document
This document is designed to be read primarily by design engineers and software
engineers who need a detailed description of the interactions of the TC1767 functional
units, registers, instructions, and exceptions.
This TC1767 Data Sheet describes the features of the TC1767 with respect to the
TriCore Architecture. Where the TC1767 directly implements TriCore architectural
functions, this manual simply refers to those functions as features of the TC1767. In all
cases where this manual describes a TC1767 feature without referring to the TriCore
Architecture, this means that the TC1767 is a direct implementation of the TriCore
Architecture.
Where the TC1767 implements a subset of TriCore architectural features, this manual
describes the TC1767 implementation, and then describes how it differs from the TriCore
Architecture. Such differences between the TC1767 and the TriCore Architecture are
documented in the section covering each such subject.
2.1.1
Related Documentations
A complete description of the TriCore architecture is found in the document entitled
“TriCore Architecture Manual”. The architecture of the TC1767 is described separately
this way because of the configurable nature of the TriCore specification: Different
versions of the architecture may contain a different mix of systems components. The
TriCore architecture, however, remains constant across all derivative designs in order to
preserve compatibility.
This Data Sheets together with the “TriCore Architecture Manual” are required to
understand the complete TC1767 micro controller functionality.
2.1.2
Text Conventions
This document uses the following text conventions for named components of the
TC1767:
• Functional units of the TC1767 are given in plain UPPER CASE. For example: “The
SSC supports full-duplex and half-duplex synchronous communication”.
• Pins using negative logic are indicated by an overline. For example: “The external
reset pin, ESR0, has a dual function.”.
• Bit fields and bits in registers are in general referenced as
“Module_Register name.Bit field” or “Module_Register name.Bit”. For example: “The
Current CPU Priority Number bit field CPU_ICR.CCPN is cleared”. Most of the
Data Sheet
7
V1.3, 2009-09
