TC1767
Introduction
Table 3
Symbol
U
Access Terms
Description
Access Mode: Access permitted in User Mode 0 or 1.
Reset Value: Value or bit is not changed by a reset operation.
Access permitted in Supervisor Mode.
SV
R
Read-only register.
32
Only 32-bit word accesses are permitted to this register/address range.
Endinit-protected register/address.
E
PW
NC
BE
nBE
Password-protected register/address.
No change, indicated register is not changed.
Indicates that an access to this address range generates a Bus Error.
Indicates that no Bus Error is generated when accessing this address
range, even though it is either an access to an undefined address or the
access does not follow the given rules.
nE
Indicates that no Error is generated when accessing this address or
address range, even though the access is to an undefined address or
address range. True for CPU accesses (MTCR/MFCR) to undefined
addresses in the CSFR range.
2.1.5
Abbreviations and Acronyms
The following acronyms and terms are used in this document:
ADC
Analog-to-Digital Converter
Address General Purpose Register
Arithmetic and Logic Unit
Asynchronous/Synchronous Serial Controller
Bus Control Unit
AGPR
ALU
ASC
BCU
BROM
CAN
Boot ROM & Test ROM
Controller Area Network
CMEM
CISC
CPS
PCP Code Memory
Complex Instruction Set Computing
CPU Slave Interface
CPU
Central Processing Unit
Data Sheet
10
V1.3, 2009-09
