S29GL01GP
S29GL512P
S29GL256P
S29GL128P
6. Product Overview
The S29GL-P family consists of 1 Gb, 512 Mb, 256 Mb and 128 Mb, 3.0-volt-only, page mode Flash devices optimized for today’s
embedded designs that demand a large storage array and rich functionality. These devices are manufactured using 90 nm MirrorBit
technology. These products offer uniform 64 Kword (128 Kbyte) uniform sectors and feature VersatileIO control, allowing control and
I/O signals to operate from 1.65 V to VCC. Additional features include:
Single word programming or a 32-word programming buffer for an increased programming speed
Program Suspend/Resume and Erase Suspend/Resume
Advanced Sector Protection methods for protecting sectors as required
128 words/256 bytes of Secured Silicon area for storing customer and factory secured information. The Secured Silicon Sector is
One Time Programmable.
6.1
Memory Map
The S29GL-P devices consist of uniform 64 Kword (128 Kbyte) sectors organized as shown in Table –Table .
S29GL01GP Sector & Memory Address Map
Uniform Sector
Size
64 Kword/128 Kbyte
Note
Sector Count Sector Range
Address Range (16-bit)
0000000h - 000FFFFh
:
Notes
SA00
Sector Starting Address
1024
:
SA1023
3FF0000H - 3FFFFFFh
Sector Ending Address
This table has been condensed to show sector-related information for an entire device on a single page. Sectors and their address ranges that are
not explicitly listed (such as SA001-SA1022) have sector starting and ending addresses that form the same pattern as all other sectors of that size.
For example, all 128 Kb sectors have the pattern xxx0000h-xxxFFFFh.
S29GL512P Sector & Memory Address Map
Sector
Uniform Sector Size
Sector Count
Range
SA00
:
Address Range (16-bit)
0000000h - 000FFFFh
:
Notes
Sector Starting Address
64 Kword/128 Kbyte
512
SA511
1FF0000H - 1FFFFFFh
Sector Ending Address
Note
This table has been condensed to show sector-related information for an entire device on a single page. Sectors and their address ranges that are
not explicitly listed (such as SA001-SA510) have sector starting and ending addresses that the same pattern as all other sectors of that size. For
example, all 128 Kb sectors have the pattern xxx0000h-xxxFFFFh.
S29GL256P Sector & Memory Address Map
Uniform Sector
Size
Sector
Count
Sector
Range
Address Range (16-bit)
0000000h - 000FFFFh
:
Notes
SA00
:
Sector Starting Address
64 Kword/
128 Kbyte
256
SA255
0FF0000H - 0FFFFFFh
Sector Ending Address
Document Number: 002-00886 Rev. *B
Page 13 of 83
