Electrical Characteristics
Table 57 Output Characteristics of CLS in NT-RP Mode
Parameter
Symbol
Limit Values
Unit Test
Condition
min.
26
max.
39
Pulse width high, low tH,tL
Rise time, fall time tR,tF
ns
ns
C
C
= 20pF
= 20pF
Load
0
13
Load
Table 58 Output Characteristics of CLS in NT-PBX and LT-RP Modes
Parameter
Symbol
Limit Values
Unit Test
Condition
min.
850
0
max.
960
30
Pulse width high, low tH,tL
Rise time, fall time tR,tF
ns
ns
C
C
= 10pF
= 10pF
Load
Load
Table 59 Output Characteristics of CLS in all other Modes1)
Parameter
Symbol
Limit Values
Unit Test
Condition
min.
40
max.
90
Pulse width high, low tH,tL
Rise time, fall time tR,tF
ns
ns
C
C
= 10pF
= 10pF
Load
0
25
Load
1) Except LT mode. Note that CLS is not defined in LT mode
