CoolSET™-F3
Electrical Characteristics
4
Electrical Characteristics
Note: All voltages are measured with respect to ground (Pin 8). The voltage levels are valid if other ratings are
not violated.
4.1
Absolute Maximum Ratings
Note: Absolute maximum ratings are defined as ratings, which when being exceeded may lead to destruction
of the integrated circuit. For the same reason make sure, that any capacitor that will be connected to pin 7
(VCC) is discharged before assembling the application circuit.
Parameter
Symbol
Limit Values
Unit
Remarks
min.
max.
Drain Source Voltage
ICE3Axx65/xx65I/xx65P
ICE3Bxx65/xx65I/xx65P
VDS
-
650
V
Tj=110°C
Avalanche energy,
repetitive tAR limited by
max. Tj=150°C1)
ICE3x0365
EAR1
EAR2
EAR3
EAR4
EAR5
EAR6
-
-
-
-
-
-
-
-
-
-
-
0.005
0.01
0.07
0.15
0.40
0.47
0.07
0.11
0.17
0.40
0.44
mJ
mJ
mJ
mJ
mJ
mJ
mJ
mJ
mJ
mJ
mJ
ICE3x0565
ICE3A0565Z
ICE3x1065
ICE3x1565
ICE3x2065
ICE3A2065Z
ICE3x2565
ICE3x2065I EAR7
ICE3x2065P
ICE3x3065I EAR8
ICE3x3065P
ICE3x3565I EAR9
ICE3x3565P
ICE3x5065I EAR10
ICE3x5065P
ICE3x5565I EAR11
ICE3x5565P
Version 1.3
19
15 Sep 2004
