TechnischeꢀInformationꢀ/ꢀTechnicalꢀInformation
IGBT-Modul
IGBT-Module
DDB6U134N16RR_B11
Diode,ꢀBrems-Chopperꢀ/ꢀDiode,ꢀBrake-Chopper
HöchstzulässigeꢀWerteꢀ/ꢀMaximumꢀRatedꢀValues
PeriodischeꢀSpitzensperrspannung
Repetitiveꢀpeakꢀreverseꢀvoltage
Tvj = 25°C
VRRM
IF
IFRM
I²t
ꢀ
ꢀ
ꢀ
ꢀ
1200
35
ꢀ
ꢀ
ꢀ
V
A
A
Dauergleichstrom
ContinuousꢀDCꢀforwardꢀcurrent
PeriodischerꢀSpitzenstrom
tP = 1 ms
70
Repetitiveꢀpeakꢀforwardꢀcurrent
Grenzlastintegral
VR = 0 V, tP = 10 ms, Tvj = 125°C
I²tꢀ-ꢀvalue
310
ꢀ A²s
CharakteristischeꢀWerteꢀ/ꢀCharacteristicꢀValues
min. typ. max.
Durchlassspannung
Forwardꢀvoltage
IF = 35 A, VGE = 0 V
IF = 35 A, VGE = 0 V
Tvj = 25°C
Tvj = 125°C
1,85 2,30
1,75
V
V
VF
Rückstromspitze
Peakꢀreverseꢀrecoveryꢀcurrent
IF = 35 A, - diF/dt = 1300 A/µs (Tvj=125°C) Tvj = 25°C
60,0
65,0
A
A
VR = 600 V
VGE = -15 V
Tvj = 125°C
IRM
Sperrverzögerungsladung
Recoveredꢀcharge
IF = 35 A, - diF/dt = 1300 A/µs (Tvj=125°C) Tvj = 25°C
3,50
7,50
µC
µC
VR = 600 V
VGE = -15 V
Tvj = 125°C
Qr
AbschaltenergieꢀproꢀPuls
Reverseꢀrecoveryꢀenergy
IF = 35 A, - diF/dt = 1300 A/µs (Tvj=125°C) Tvj = 25°C
1,30
2,80
mJ
mJ
VR = 600 V
VGE = -15 V
Tvj = 125°C
Erec
Wärmewiderstand,ꢀChipꢀbisꢀGehäuse
Thermalꢀresistance,ꢀjunctionꢀtoꢀcase
proꢀDiodeꢀ/ꢀperꢀdiode
RthJC
RthCH
Tvj op
0,80 K/W
K/W
Wärmewiderstand,ꢀGehäuseꢀbisꢀKühlkörper proꢀDiodeꢀ/ꢀperꢀdiode
Thermalꢀresistance,ꢀcaseꢀtoꢀheatsink
0,42
λPasteꢀ=ꢀ1ꢀW/(m·K)ꢀꢀꢀ/ꢀꢀꢀꢀλgreaseꢀ=ꢀ1ꢀW/(m·K)
TemperaturꢀimꢀSchaltbetrieb
Temperatureꢀunderꢀswitchingꢀconditions
-40
125
°C
preparedꢀby:ꢀCM
approvedꢀby:ꢀRS
dateꢀofꢀpublication:ꢀ2014-08-29
revision:ꢀ3.0
