AIROC™ Bluetooth® system on chip for automotive applications

Specifications

11.1

Electrical characteristics

The absolute maximum ratings in Table 8 indicate levels where permanent damage to the device can occur, even

if these limits are exceeded for only a brief duration. Functional operation is not guaranteed under these condi-

tions. Operation at absolute maximum conditions for extended periods can adversely affect long-term reliability

of the device.

Table 8

Absolute maximum ratings

Specification

Min

–

–0.5

Requirement parameter

Unit

°C

Nom

–

Max

125

Maximum junction temperature

VDDO1/VDDO2

IFVDD/PLLVDD/VCOVDD/VDDC

PMUAVDD/SR_PVDD

DIGLDO_VDDIN

RFLDO_VDDIN

PALDO_VDDIN

PAVDD

–

3.795

1.38

3.795

1.65

3.79

2.75

2.5

Table 9

ESD/latchup

Specification

Requirement parameter

Unit

Min

–2000

–500

–

Nom

–

200

Max

2000

500

–

ESD Tolerance HBM

ESD Tolerance CDM

Latch-up

Table 10

Environmental ratings

Characteristic

Value

Unit

Operating Temperature

Storage Temperature

–40 to +105

–40 to +150

°C

Datasheet

002-25826 Rev. *G

2022-09-24
