EZ-PD™ CCG7D Automotive USB Type-C and Buck-boost Controller
Dual-port
Electrical specifications
6.4
System resources
6.4.1
Power-on-reset (POR) with brown out
Table 23
Imprecise power-on reset (IPOR)
Spec ID
Parameter Description
Min Typ Max Unit Details/conditions
Power-on reset (POR) rising
SID185
SID186
VRISEIPOR
VFALLIPOR
0.80
0.70
1.50
1.4
–40°C ≤TA ≤ +105°C,
All VDDD
trip voltage
–
V
POR falling trip voltage
Table 24
Spec ID
Precise POR
Parameter Description
Min Typ Max Unit Details/conditions
Brown-out detect (BOD) trip
SID190
SID192
VFALLPPOR
VFALLDPSLP
voltage in Active/Sleep
modes
1.48
1.1
1.62
1.5
–40°C ≤ TA ≤ +105°C,
All VDDD
–
V
BOD trip voltage in Deep
Sleep mode
6.4.2
SWD interface
Table 25
SWD interface specifications
Spec ID
Parameter
Description
Min
Typ
Max Unit Details/conditions
SID.SWD#1 F_SWDCLK1
3.0 V VDDIO 5.5 V
–
14
MHz
SID.SWD#2 T_SWDI_SETUP
SID.SWD#3 T_SWDI_HOLD
SID.SWD#4 T_SWDO_VALID
SID.SWD#5 T_SWDO_HOLD
0.25 × T
–
–
–
T = 1/f SWDCLK
ns
–
1
0.50 × T
–
6.4.3
IMO
Table 26
IMO AC specifications
Spec ID
Parameter Description
Min Typ Max Unit Details/conditions
Frequency variation at
48 MHz (trimmed)
IMO start-up time
IMO frequency
3.0 V ≤ VDDD < 5.5 V.
SID.CLK#13 FIMOTOL
±2
7
%
–40°C ≤ TA ≤ 105°C
–
–
SID226
TSTARTIMO
FIMO
µs
–40°C ≤ TA ≤ +105°C,
All VDDD
SID.CLK#1
24
48 MHz
6.4.4
Internal low-speed oscillator
ILO AC specifications
Table 27
Spec ID
SID234
SID238
SID.CLK#5
Parameter Description
Min Typ Max Unit Details/conditions
TSTARTILO1
TILODUTY
FILO
ILO start-up time
ILO duty cycle
ILO frequency
–
40
20
–
50
40
2
60
ms
%
–40°C ≤ TA ≤ +105°C,
All VDDD
80 kHz –
Datasheet
39
002-28172 Rev. *N
2023-01-31
