Electrical specifications
Table 31
Spec ID
High-side CSA AC specifications
Parameter Description
Min Typ Max Unit Details/conditions
Delay from SCP
threshold trip to
external NFET power
gate turn off
TSCP_GATE
SID.HSCSA.AC.1
SID.HSCSA.AC.2
3.5
8
1 nF NFET gate
3 nF NFET gate
–
–
µs
Delay from SCP
threshold trip to
external NFET power
gate turn off
TSCP_GATE_1
6.4.8
UV/OV
Table 32
UV/OV Specifications
Spec ID
Parameter Description
Min Typ Max Unit Details/conditions
Overvoltage threshold
SID.UVOV.1
SID.UVOV.2
SID.UVOV.3
SID.UVOV.4
SID.UVOV.5
VTHOV1
VTHOV2
VTHUV1
VTHUV2
VTHUV3
–3
–3.2
–4
3
3.2
4
Accuracy, 4 V to 11 V
Overvoltage threshold
Accuracy, 11 V to 21.5 V
Undervoltage threshold
Accuracy, 3 V to 3.3 V
Undervoltage threshold
Accuracy, 3.3 V to 4.0 V
Undervoltage threshold
Accuracy, 4.0 V to 21.5 V
–
%
Active mode
–3.5
–3
3.5
3
6.4.9
VCONN switch
Table 33
VCONN switch DC specifications
Spec ID
Parameter
Description
Min Typ Max Unit Details/conditions
VCONN output voltage
with 20 mA load current
Connector side pin
leakage current
DC.VCONN.1 VCONN_OUT
DC.VCONN.2 ILEAK
4.5
–
5.5
10
V
–
µA
–
VCONN Over-Current
Protection Threshold
DC.VCONN.3 IOCP
22.5 30 37.5 mA
Table 34
VCONN switch AC specifications
Parameter Description
Spec ID
Min Typ Max Unit Details/conditions
AC.VCONN.1 TON
AC.VCONN.2 TOFF
VCONN switch turn-on time
VCONN switch turn-off time
600
10
–
–
µs
–
Datasheet
42
002-28172 Rev. *N
2023-01-31
