BTS 432 E2
Parameter and Conditions
Symbol
Values
Unit
at Tj = 25 °C, V = 12 V unless otherwise specified
bb
min
typ
max
Input and Status Feedback11)
Input turn-on threshold voltage
VIN(T+)
1.5
1.0
--
--
2.4
--
V
V
Tj =-40..+150°C:
Input turn-off threshold voltage
VIN(T-)
Tj =-40..+150°C:
Input threshold hysteresis
∆ VIN(T)
--
1
0.5
--
--
V
Off state input current (pin 2)
VIN = 0.4 V: IIN(off)
VIN = 3.5 V: IIN(on)
td(ST SC)
30
µA
On state input current (pin 2)
10
80
25
50
µA
µs
µs
Status invalid after positive input slope
(short circuit)
200
400
T =-40 ... +150°C:
j
Status invalid after positive input slope
td(ST)
350
-- 1600
(open load)
T =-40 ... +150°C:
j
Status output (open drain)
Zener limit voltage T =-40...+150°C, IST = +1.6 mA: VST(high)
5.4
--
6.1
--
--
0.4
V
j
ST low voltage T =-40...+150°C, IST = +1.6 mA: VST(low)
j
11)
If a ground resistor R
is used, add the voltage drop across this resistor.
GND
Semiconductor Group
5
