■Crimp Sockets (Height, Long Type)
Shown with terminated and installed contacts.
Shown with terminated and installed contacts.
A
1 Pos.
2 to 5 Pos.
B
8
P=7.92
Type 4
Type 3
Height: Long type, Height: Long type,
Type 4
Type 3
Enhanced
ergonomic lock
Standard lock
Height: Long type, Height: Long type,
Enhanced
ergonomic lock
Standard lock
Contact No. 1
No. of contacts
indicator
(12.75)
(11.55)
Cavity No.
Contact No. 1
indicator
(12.75)
(11.55)
A
1
A
3
No. of contacts
indicator
Cavity No.
■ Type III
■ Type IV
Height: Long type, Standard lock
Height: Long type, Enhanced ergonomic lock
Standard Type (Guide Key: Inside, Color: White)
Standard Type (Guide Key: Inside, Color: White)
Part Number
DF22B-1S-7.92C
DF22B-2S-7.92C
DF22B-3S-7.92C
DF22B-4S-7.92C
DF22B-5S-7.92C
CL No.
Number of contacts
A
B
Part Number
DF22C-1S-7.92C
DF22C-2S-7.92C
DF22C-3S-7.92C
DF22C-4S-7.92C
DF22C-5S-7.92C
CL No.
Number of contacts
A
B
680-1096-2
680-1097-5
680-1098-8
680-1099-0
680-1100-8
1
2
3
4
5
8.00 -----
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
680-1101-0
680-1102-3
680-1103-6
680-1104-9
680-1105-1
1
2
3
4
5
8.00 -----
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
R Type (Guide Key: Right Side, Color: Black)
R Type (Guide Key: Right Side, Color: Black)
Part Number
DF22BR-1S-7.92C
DF22BR-2S-7.92C
DF22BR-3S-7.92C
DF22BR-4S-7.92C
DF22BR-5S-7.92C
CL No.
Number of contacts
A
B
Part Number
DF22CR-1S-7.92C
DF22CR-2S-7.92C
DF22CR-3S-7.92C
DF22CR-4S-7.92C
DF22CR-5S-7.92C
CL No.
Number of contacts
A
B
1
2
3
4
5
8.00 -----
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
1
2
3
4
5
8.00 -----
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
Reserved for
Reserved for
product expansion
product expansion
L Type (Guide Key: Left Side, Color: Red)
L Type (Guide Key: Left Side, Color: Red)
Part Number
DF22BL-1S-7.92C
DF22BL-2S-7.92C
DF22BL-3S-7.92C
DF22BL-4S-7.92C
DF22BL-5S-7.92C
CL No.
Number of contacts
A
B
Part Number
DF22CL-1S-7.92C
DF22CL-2S-7.92C
DF22CL-3S-7.92C
DF22CL-4S-7.92C
DF22CL-5S-7.92C
CL No.
Number of contacts
A
B
1
2
3
4
5
8.00 -----
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
1
2
3
4
5
8.00 -----
15.50 7.92
23.42 15.84
31.34 23.76
39.26 31.68
Reserved for
Reserved for
product expansion
product expansion
Note: Bag packaging (100 pieces/bag). Order by number of bags.
4
