Isolated Modulator
Ordering Information
Specify Part Number followed by Option Number (if desired).
Example:
HCPL-7860#XXX
No Option = Standard DIP package, 50 per tube.
300 = Gull Wing Surface Mount Option, 50 per tube.
500 = Tape and Reel Packaging Option, 1000 per reel.
Option data sheets available. Contact Hewlett-Packard sales representative or authorized distributor.
Package Outline Drawings
8-pin DIP Package
9.40 (0.370)
9.90 (0.390)
8
1
7
6
5
REFERENCE VOLTAGE
MATCHING SUFFIX*
TYPE NUMBER
0.18 (0.007)
0.33 (0.013)
6.10 (0.240)
6.60 (0.260)
DATE CODE
HP 7860X
YYWW
7.36 (0.290)
7.88 (0.310)
5° TYP.
2
3
4
PIN ONE
1.78 (0.070) MAX.
1.19 (0.047) MAX.
4.70 (0.185) MAX.
PIN DIAGRAM
1
2
V
V
V
8
7
DD1
IN+
DD2
PIN ONE
0.51 (0.020) MIN.
MCLK
MDAT
2.92 (0.115) MIN.
V
3
4
6
5
IN–
0.76 (0.030)
1.24 (0.049)
0.65 (0.025) MAX.
GND1 GND2
2.28 (0.090)
2.80 (0.110)
DIMENSIONS IN MILLIMETERS AND (INCHES).
*ALL UNITS WITHIN EACH HCPL-7860 STANDARD PACKAGING INCREMENT (EITHER 50 PER TUBE OR 1000 PER REEL)
HAVE A COMMON MARKING SUFFIX TO REPRESENT AN ABSOLUTE REFERENCE VOLTAGE TOLERANCE OF ± 1%.
AN ABSOLUTE REFERENCE VOLTAGE TOLERANCE OF ± 4% IS GUARANTEED BETWEEN STANDARD PACKAGING
INCREMENTS.
