300
250
200
150
100
P
P
, OUTPUT
, INPUT
Si
Si
MAX. OPERATING
TEMP. IS 100 °C
50
0
0
50
100
150
200
T
– TEMPERATURE – °C
A
Figure 13. Dependence of Safety-
Limiting Values on Temperature.
Insulation and Safety Related Specifications
Parameter
Symbol Value Units
Conditions
Minimum External Air Gap
(Clearance)
Minimum External Tracking
(Creepage)
Minimum Internal Plastic Gap
(Internal Clearance)
L(I01)
7.4
8.0
0.5
mm
mm
mm
Measured from input terminals to output
terminals, shortest distance through air.
Measured from input terminals to output
terminals, shortest distance path along body
Insulation thickness between emitter and
detector; also known as distance through
insulation.
L(I02)
Tracking Resistance
(Comparative Tracking Index)
Isolation Group
CTI
175
IIIa
Volts DIN IEC 112/VDE 0303 Part 1
Material Group (DIN VDE 0110, 1/89, Table 1)
Option 300 - surface mount classification is Class A in accordance with CECC 00802.
Absolute Maximum Ratings
Parameter
Storage Temperature
Ambient Operating Temperature
Supply Voltages
Steady-State Input Voltage
Two Second Transient Input Voltage
Output Voltages
Lead Solder Temperature
Solder Reflow Temperature Profile
Symbol
Min.
-55
-40
0
-2.0
-6.0
-0.5
Max.
125
+85
5.5
Units
°C
°C
Volts
Volts
Note
T
S
T
A
V
, V
DD1 DD2
V
, V
V
+ 0.5
16
17
IN+ IN-
DD1
MCLK, MDAT
V
+0.5
Volts
DD2
260°C for 10 sec., 1.6 mm below seating plane
See Maximum Solder Reflow Thermal Profile section
Recommended Operating Conditions
Parameter
Ambient Operating Temperature
Supply Voltages
Symbol
Min.
-40
4.5
Max.
+85
5.5
Units
°C
V
Note
T
A
V
, V
DD1 DD2
Input Voltage
V
, V
-200
+200
mV
16
IN+ IN-
1-270
