Preliminary
HT48R06A-1
ADDM A,[m]
Add the accumulator to the data memory
Description
The contents of the specified data memory and the accumulator are added.
The result is stored in the data memory.
Operation
[m] ¬ ACC+[m]
Affected flag(s)
TC2 TC1 TO PD OV
Z
AC
C
¾
¾
¾
¾
Ö
Ö
Ö
Ö
AND A,[m]
Logical AND accumulator with data memory
Description
Data in the accumulator and the specified data memory perform a bitwise
logical_AND operation. The result is stored in the accumulator.
Operation
ACC ¬ ACC "AND" [m]
Affected flag(s)
TC2 TC1 TO PD OV
Z
AC
C
¾
¾
¾
¾
¾
Ö
¾
¾
AND A,x
Logical AND immediate data to the accumulator
Description
Data in the accumulator and the specified data perform a bitwise logi-
cal_AND operation. The result is stored in the accumulator.
Operation
ACC ¬ ACC "AND" x
Affected flag(s)
TC2 TC1 TO PD OV
Z
AC
C
¾
¾
¾
¾
¾
Ö
¾
¾
ANDM A,[m]
Logical AND data memory with the accumulator
Description
Data in the specified data memory and the accumulator perform a bitwise
logical_AND operation. The result is stored in the data memory.
Operation
[m] ¬ ACC "AND" [m]
Affected flag(s)
TC2 TC1 TO PD OV
Z
AC
C
¾
¾
¾
¾
¾
Ö
¾
¾
28
February 25, 2000
HOLTEK [ HOLTEK SEMICONDUCTOR INC ]
