HT45FH4M
Lithium Battery Backup Power ASSP MCU
Flash Program Memory
TheꢀProgramꢀMemoryꢀisꢀtheꢀlocationꢀwhereꢀtheꢀuserꢀcodeꢀorꢀprogramꢀisꢀstored.ꢀForꢀthisꢀdeviceꢀtheꢀ
ProgramꢀMemoryꢀisꢀFlashꢀtype,ꢀwhichꢀmeansꢀitꢀcanꢀbeꢀprogrammedꢀandꢀre-programmedꢀaꢀlargeꢀ
numberꢀofꢀtimes,ꢀallowingꢀtheꢀuserꢀtheꢀconvenienceꢀofꢀcodeꢀmodificationꢀonꢀtheꢀsameꢀdevice.ꢀ
Byꢀusingꢀtheꢀappropriateꢀprogrammingꢀtools,ꢀthisꢀFlashꢀdeviceꢀoffersꢀusersꢀtheꢀflexibilityꢀtoꢀ
convenientlyꢀdebugꢀandꢀdevelopꢀtheirꢀapplicationsꢀwhileꢀalsoꢀofferingꢀaꢀmeansꢀofꢀfieldꢀprogrammingꢀ
andꢀupdating.
Structure
TheꢀProgramꢀMemoryꢀhasꢀaꢀcapacityꢀofꢀ2K×16ꢀbits.ꢀTheꢀProgramꢀMemoryꢀisꢀaddressedꢀbyꢀtheꢀ
ProgramꢀCounterꢀandꢀalsoꢀcontainsꢀdata,ꢀtableꢀinformationꢀandꢀinterruptꢀentries.ꢀTableꢀdata,ꢀwhichꢀ
canꢀbeꢀsetupꢀinꢀanyꢀlocationꢀwithinꢀtheꢀProgramꢀMemory,ꢀisꢀaddressedꢀbyꢀaꢀseparateꢀtableꢀpointerꢀ
register.
Special Vectors
WithinꢀtheꢀProgramꢀMemory,ꢀcertainꢀlocationsꢀareꢀreservedꢀforꢀtheꢀresetꢀandꢀinterrupts.ꢀTheꢀlocationꢀ
000Hꢀisꢀreservedꢀforꢀuseꢀbyꢀtheꢀdeviceꢀresetꢀforꢀprogramꢀinitialisation.ꢀAfterꢀaꢀdeviceꢀresetꢀisꢀ
initiated,ꢀtheꢀprogramꢀwillꢀjumpꢀtoꢀthisꢀlocationꢀandꢀbeginꢀexecution.
