MB85RC64
■ ABSOLUTE MAXIMUM RATINGS
Rating
Parameter
Symbol
Unit
Max
Min
Power supply voltage*
Input pin voltage*
VCC
VIN
− 0.5
− 0.5
− 0.5
− 40
− 40
+4.0
V
VCC + 0.5 ( ≤ 4.0)
VCC + 0.5 ( ≤ 4.0)
+ 85
V
Output pin voltage*
Ambient temperature
Storage temperature
VOUT
TA
V
°C
°C
Tstg
+ 125
*: These parameters are based on the condition that VSS is 0 V.
WARNING: Semiconductor devices can be permanently damaged by application of stress (voltage, current,
temperature, etc.) in excess of absolute maximum ratings. Do not exceed these ratings.
■ RECOMMENDED OPERATING CONDITIONS
Value
Parameter
Symbol
Unit
Min
Typ
Max
Power supply voltage*
“H” level input voltage*
VCC
VIH
2.7
3.3
3.6
V
V
VCC + 0.5
( ≤ 4.0)
VCC × 0.8
⎯
“L” level input voltage*
Ambient temperature
VIL
− 0.5
− 40
⎯
⎯
+ 0.6
+ 85
V
TA
°C
*: These parameters are based on the condition that VSS is 0 V.
WARNING: The recommended operating conditions are required in order to ensure the normal operation of
the semiconductor device. All of the device's electrical characteristics are warranted when the
device is operated within these ranges.
Always use semiconductor devices within their recommended operating condition ranges.
Operation outside these ranges may adversely affect reliability and could result in device failure.
No warranty is made with respect to uses, operating conditions, or combinations not represented
onthedatasheet.Usersconsideringapplicationoutsidethelistedconditionsareadvisedtocontact
their representatives beforehand.
