General Description
1.2 Introduction
The MC68HC705C8A, an enhanced version of the MC68HC705C8, is a
member of the low-cost, high-performance M68HC05 Family of 8-bit
microcontroller units (MCU). The MC68HSC705C8A, introduced in
Appendix A. MC68HSC705C8A, is an enhanced, high-speed version of
the MC68HC705C8A. The M68HC05 Family is based on the
customer-specified integrated circuit (CSIC) design strategy. All MCUs
in the family use the M68HC05 central processor unit (CPU) and are
available with a variety of subsystems, memory sizes and types, and
package types.
1.3 Features
Features of the MC68HC705C8A include:
• M68HC05 central processor unit (CPU)
• On-chip oscillator with crystal/ceramic resonator
• Memory-mapped input/output (I/O)
• Selectable memory configurations
• Selectable programmable and/or non-programmable computer
operating properly (COP) watchdog timers
• Selectable port B external interrupt capability
• Clock monitor
• High current drive on pin C7 (PC7)
• 24 bidirectional I/O lines and 7 input-only lines
• Serial communications interface (SCI) system
• Serial peripheral interface (SPI) system
• Bootstrap capability
• Power-saving stop, wait, and data-retention modes
• Single 3.0-volt to 5.5-volt supply (2-volt data-retention mode)
• Fully static operation
