MAXIMUM RATINGS
MAXIMUM RATINGS
Table 2. Maximum Ratings
All voltages are with respect to ground unless otherwise noted. Exceeding these ratings may cause a malfunction or permanent
damage to the device.
Rating
Symbol
Value
Unit
Electrical Ratings
Supply Voltage
V
V
, V
-0.3 to 7.0
-1.0 to 7.0
-0.3 to 8.5
-0.3 to 8.5
-0.3 to 9.5
-0.3 to 7.0
-0.3 to 7.0
-0.3 to 7.0
V
V
V
V
V
V
V
V
V
IN1 IN2
Switching Node Voltage
V
SW
IN(BOOT)
Buck Regulator Bootstrap Input Voltage (BOOT - SW)
Boost Regulator Output Voltage
Boost Regulator Drain Voltage
V
BST
V
BD
RST Drain Voltage
V
RST
Enable Terminal Voltage at EN1, EN2
Logic Terminal Voltage at SDA, SCL
V
EN
V
LOG
Analog Terminal Voltage
LDO, VOUT, RST
-0.3 to 7.0
-0.3 to 8.5
V
OUT
LDRV, LCMP, CS
V
LIN
Terminal Voltage at CLKSEL, ADDR, RT, FREQ, VDDI, CLKSYN, INV,
LFB
-0.3 to 3.6
V
V
V
LOGIC
ESD Voltage (1)
Human Body Model
Machine Model
±2000
±200
V
ESD
Thermal Ratings
Storage Temperature
T
-65 to 150
260
°C
°C
STG
Lead Soldering Temperature (2)
Maximum Junction Temperature
T
SOLDER
T
125
°C
JMAX
Thermal Resistance
R
°C/W
θJA
(4)
Junction to Ambient (Single Layer) (3)
,
70
55
(4)
Junction to Ambient (Four Layers) (3)
,
Thermal Resistance, Junction to Base (5)
R
18
°C/W
θJB
Operational Package Temperature (Ambient Temperature)
Notes
T
-40 to 85
°C
A
1. ESD1 testing is performed in accordance with the Human Body Model (CZAP=100 pF, RZAP=1500 Ω), ESD2 testing is performed in
accordance with the Machine Model (CZAP=200 pF, RZAP=0 Ω), and the Charge Device Model.
2. Lead soldering temperature limit is for 10 seconds maximum duration.
3. Junction temperature is a function of on-chip power dissipation, package thermal resistance, mounting site (board) temperature,
ambient temperature, air flow, power dissipation of other components on the board and board thermal resistance.
4. Per JEDEC JESD51-6 with the board horizontal
5. Thermal resistance between the die and the printed circuit board per JEDEC JESD51-8. Board temperature is measured on the top
surface of the board near the package.
34701
Analog Integrated Circuit Device Data
Freescale Semiconductor
5
