DSP56371 Overview
2
12
12
11
5
Memory Expansion Area
Triple
Timer
ESAI_1
Interface
GPIO
EFCOP
SHI
Interface
ESAI
Interface
X Data
RAM
Y Data
RAM
Program
RAM
48K × 24
36K × 24
4K × 24
ROM
64K × 24
ROM
32K × 24
ROM
32K × 24
2
DAX
Peripheral
Expansion Area
YAB
XAB
PAB
DAB
Address
Generation
Unit
Six Channel
DMA Unit
24-Bit
Bootstrap
ROM
DSP56300
Core
DDB
YDB
XDB
PDB
GDB
Internal
Data
Bus
Switch
Power
Mngmnt.
Clock
Gen-
erator
4
Data ALU
Program
Interrupt
Controller
Program
Decode
Controller
Program
JTAG
PLL
+
→
Address
24 × 24 56 56-bit MAC
Two 56-bit Accumulators
56-bit Barrel Shifter
OnCE™
Generator
MODA/IRQA
MODB/IRQB
MODC/IRQC
MODD/IRQD
EXTAL
RESET
PINIT/NMI
Figure 1. DSP56371 Block Diagram
2.2
DSP56300 Core Description
The DSP56371 uses the DSP56300 core, a high-performance, single clock cycle per instruction engine that provides up to twice
the performance of Motorola's popular DSP56000 core family while retaining code compatibility with it.
The DSP56300 core family offers a new level of performance in speed and power, provided by its rich instruction set and low
power dissipation, thus enabling a new generation of wireless, telecommunications and multimedia products. For a description
of the DSP56300 core, see Section 2.4 DSP56300 Core Functional Blocks. Significant architectural enhancements to the
DSP56300 core family include a barrel shifter, 24-bit addressing, an instruction patch module and direct memory access (DMA).
The DSP56300 core family members contain the DSP56300 core and additional modules. The modules are chosen from a library
of standard predesigned elements such as memories and peripherals. New modules may be added to the library to meet
customer specifications. A standard interface between the DSP56300 core and the on-chip memory and peripherals supports a
wide variety of memory and peripheral configurations. Refer to DSP56371 User Manual, Section 3, Memory Configuration.
Core features are described fully in the DSP56300 Family Manual. Pinout, memory and peripheral features are described in this
manual.
2
DSP56371 Technical Data
