Enhanced Capture Timer
Timer Registers
to the TCNT register ($84, $85) clears the TOF flag. Any
access to the PACN3 and PACN2 registers ($A2, $A3) clears
the PAOVF and PAIF flags in the PAFLG register ($A1). Any
access to the PACN1 and PACN0 registers ($A4, $A5) clears
the PBOVF flag in the PBFLG register ($B1). Any access to the
MCCNT register ($B6, $B7) clears the MCZF flag in the
MCFLG register ($A7). This has the advantage of eliminating
software overhead in a separate clear sequence. Extra care is
required to avoid accidental flag clearing due to unintended
accesses.
Bit 7
0
6
0
5
0
4
0
3
0
2
0
1
0
Bit 0
0
RESET:
TQCR — Reserved
$0087
Bit 7
OM7
6
5
4
3
2
1
OM4
0
Bit 0
OL4
0
OL7
0
OM6
0
OL6
0
OM5
0
OL5
0
RESET:
0
TCTL1 — Timer Control Register 1
$0088
