FTGL2025S1TUx Pigtailed SFF Product Specification -April, 2008
F i n i s a r
II.
Absolute Maximum Ratings
Parameter
Maximum Supply Voltage
Storage Temperature
Case Operating Temperature
Relative Humidity
Fiber Output Power (no damage)
Optical Input Power (no damage)
Symbol
Vcc
TS
TOP
RH
Pf
Min
0
-40
-40
0
Typ
Max
4.3
85
85
95
20
5
Unit
V
°C
°C
%
Ref.
1
dBm
dBm
PIN
III.
Electrical Characteristics (TOP = -40 to 85 °C, VCC = 3.1 to 3.5 Volts)
Parameter
Supply Voltage
Supply Current
Symbol
Vcc
Min
3.00
Typ
3.3
Max
3.60
450
Unit
V
mA
Ref.
Icc
Transmitter
Input Differential Impedance
Differential Data Input Voltage
Transmit Disable Voltage
Transmit Enable Voltage
Transmit Disable Assert Time
Receiver
Rin
Vin,pp
VD
100
Ω
mV
V
V
μs
500
2.0
0
1600
Vcc
0.8
VEN
10
Output Differential Impedance
Differential Data Output Voltage
100
Ω
mV
Vout,pp,
LVPECL
tr, tf
VSD fault
VLOS norm
PSR
500
1800
ps
V
V
Data Output Rise and Fall Time
SD Fault
SD Normal
350
0.5
Vcc
2
0
2.4
100
Power Supply Rejection
mVpp
3
Notes:
1. Non condensing.
2. 20 – 80 %
3. 0.01 to 10 MHz
