Maximum Data Rate(15, 16)
For output load, see Table 2.
TA=-40°C to +85°C
VCCB=4.5V to VCCB=3.0V to VCCB=2.3V to VCCB=1.65V
VCCA
Direction
Units
5.5V
Min.
100
3.6V
Min.
100
2.7V
Min.
80
to 1.95V
Min.
A-to-B
B-to-A
A-to-B
B-to-A
A-to-B
B-to-A
A-to-B
B-to-A
60
VCCA=4.5V to 5.5V
VCCA=3.0V to 3.6V
VCCA=2.3V to 2.7V
100
100
100
80
100
100
100
80
80
80
80
60
60
60
40
80
60
80
40
60
40
40
Mbps
80
80
80
80
VCCA=1.65V to 1.95V
60
60
Notes:
15. Maximum data rate is guaranteed, but not tested in production.
16. Maximum data rate is specified in megabits per second with all outputs switching, (see Figure 10). It is
equivalent to two times the F-toggle frequency, specified in megahertz. For example, 100Mbps is equivalent to
50MHz.
Capacitance
TA=+25°C.
Symbol
Parameter
Conditions
Typical
Unit
CIN
CI/O
CPD
Input Capacitance, Control Pin /(OE) VCCA=VCCB=GND
An
3
4
pF
pF
pF
Input / Output Capacitance
VCCA=VCCB=5.0V, /OE=VCCA
Bn
5
Power Dissipation Capacitance
VCCA=VCCB=5.0V, VIN=0V or VCC, f=10MHz
28
© 2010 Fairchild Semiconductor Corporation
FXMA108 • Rev. 1.0.1
www.fairchildsemi.com
11
