Absolute Maximum Ratings (TJ = 25°C, Unless Otherwise Specified)
Inverter Part
Symbol
VPN
Parameter
Conditions
Applied between P- NU, NV, NW
Applied between P- NU, NV, NW
Rating
450
Units
Supply Voltage
V
V
VPN(Surge)
VCES
± IC
Supply Voltage (Surge)
500
Collector-emitter Voltage
600
V
Each IGBT Collector Current
Each IGBT Collector Current (Peak)
Collector Dissipation
TC = 25°C
30
A
± ICP
PC
TC = 25°C, Under 1ms Pulse Width
TC = 25°C per One Chip
(Note 1)
60
A
106
W
°C
TJ
Operating Junction Temperature
-40 ~ 150
Note:
1. The maximum junction temperature rating of the power chips integrated within the SPM is 150°C(@T ≤ 125°C).
C
Control Part
Symbol
VCC
Parameter
Conditions
Rating
20
Units
Control Supply Voltage
Applied between VCC(H), VCC(L) - COM
V
V
VBS
High-side Control Bias
Voltage
Applied between VB(U) - VS(U), VB(V) - VS(V)
,
,
20
V
B(W) - VS(W)
VIN
Input Signal Voltage
Applied between IN(UH)
,
IN(VH)
,
IN(WH)
-0.3~17
V
IN(UL), IN(VL), IN(WL) - COM
Applied between VFO - COM
Sink Current at VFO Pin
VFO
IFO
Fault Output Supply Voltage
Fault Output Current
-0.3~VCC+0.3
5
V
mA
V
VSC
Current Sensing Input Voltage
Applied between CSC - COM
-0.3~VCC+0.3
Bootstrap Diode Part
Symbol
Parameter
Conditions
Rating
600
Units
VRRM
IF
Maximum Repetitive Reverse Voltage
Forward Current
V
A
TC = 25°C
0.5
IFP
TJ
Forward Current (Peak)
TC = 25°C, Under 1ms Pulse Width
2
A
Operating Junction Temperature
-40 ~ 150
°C
Total System
Symbol
Parameter
Conditions
Rating
Units
VPN(PROT) Self Protection Supply Voltage Limit
(Short Circuit Protection Capability)
VCC = VBS = 13.5 ~ 16.5V
TJ = 150°C, Non-repetitive, less than 2μs
400
V
TC
Module Case Operation Temperature
Storage Temperature
-40°C≤ TJ ≤ 150°C, See Figure 2
-40 ~ 125
-40 ~ 150
2500
°C
°C
TSTG
VISO
Isolation Voltage
60Hz, Sinusoidal, AC 1 minute, Connection
Pins to heat sink plate
Vrms
Thermal Resistance
Symbol
Parameter
Conditions
Min. Typ. Max. Units
Rth(j-c)Q
Rth(j-c)F
Junction to Case Thermal
Resistance
Inverter IGBT part (per 1/6 module)
Inverter FWD part (per 1/6 module)
-
-
-
-
1.17
1.87
°C/W
°C/W
Note:
2. For the measurement point of case temperature(T ), please refer to Figure 2.
C
5
