Regulatory information
ISED (Innovation, Science and Economic Development Canada)
n
if you reduce or enlarge the size of your marking, the letters forming the UKCA marking must
be in proportion to the version set out below
n
n
n
the UKCA marking is at least 5 mm in height – unless a different minimum dimension is
specified in the relevant legislation
the UKCA marking is easily visible, legible (from 1 January 2023 it must be permanently
attached)
the UKCA marking can take different forms (for example, the colour does not have to be solid),
as long as it remains visible, legible and maintains the required proportions.
Important note
Digi customers assume full responsibility for learning and meeting the required guidelines for each
country in their distribution market. Refer to the radio regulatory agency in the desired countries of
operation for more information.
Listen Before Talk requirement
The XBee/XBee-PRO S2C 802.15.4 RF Module must be configured to comply with the Listen Before Talk
(LBT) requirements in the EN 300 328 standard. This can be accomplished by one of the following
options:
1. Set the PL command to 3 (6 dBm) or lower, which ensures that the maximum transmitter
power is under the limit at which LBT is required.
or
2. Set the CA command as described in CA (CCA Threshold) to enable LBT at the required noise
threshold level.
Declarations of conformity
Digi has issued Declarations of Conformity for the XBee RF Modules concerning emissions, EMC, and
safety. For more information, see www.digi.com/resources/certifications.
Antennas
The following antennas have been tested and approved for use with the XBee/XBee-PRO S2C 802.15.4
RF Module:
All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an
antenna manufacturer for an equivalent option.
n
Dipole (2.1 dBi, Omni-directional, Articulated RPSMA, Digi part number A24-HABSM)
n
PCB Antenna (0.0 dBi)
n
Monopole Whip (1.5 dBi)
ISED (Innovation, Science and Economic Development Canada)
Labeling requirements
Labeling requirements for Industry Canada are similar to those of the FCC. A clearly visible label on
the outside of the final product enclosure must display the following text:
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
162
