Required antenna cable loss
(dB)
Part
number
Gain
(dBi)
Min.
separation
Channels 11-
Type (description)
Yagi (12-element)
Application*
Fixed
23†
1.4
1.4
1.9
2.9
2.9
4.4
Channel 24†
A24-Y12NF
A24-Y13NF
A24-Y15NF
A24-Y16NF
A24-Y16RM
A24-Y18NF
12.0
12.0
12.5
13.5
13.5
15.0
2 m
2 m
2 m
2 m
2 m
2 m
4.4
4.4
4.9
5.9
5.9
7.4
Yagi (13-element)
Fixed
Yagi (15-element)
Fixed
Yagi (16-element)
Fixed
Yagi (16-element, RPSMA connector)
Yagi (18-element)
Fixed
Fixed
* If using the RF module in a portable application (for example - if the module is used in a handheld device and the antenna is less than 25 cm from the
human body when the device is in operation): The integrator is responsible for passing additional SAR (Specific Absorption Rate) testing based on FCC
rules 2.1091 and FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields, OET Bulletin and Supplement C. The testing results will
be submitted to the FCC for approval prior to selling the integrated unit. The required SAR testing measures emissions from the module and how they
affect the person.
† Although certified to operate on channels 11-24, currently this product only supports channels 12-23.
