SMP Customer Tooling
Accurate assembly of the Semi-Rigid Cabled Connectors is obtained with the tools listed below. Industry standard devices are used if possible for
customer convenience and tool compatibility.
E.
C.
F.
B.
G.
D.
H.
I.
J.
A.
Item
A
B
C
D
Description
SMP Bullet Extraction Tool
Part Number
127-0000-900
127-0000-901
140-0000-962
140-0000-981
140-0000-964
140-0000-997
140-0000-984
127-0000-902
127-0000-903
127-0000-904
127-0000-905
127-0000-906
127-0000-907
SMP Cabled Connector Removal Tool
Soldering Vise (does not include clamp inserts or stop screw)
Stop Screw for Soldering Vise
Semi-Rigid Cable Clamp Inserts for .086" OD Cable
Semi-Rigid Cable Clamp Inserts for .047" OD Cable
Solder Shim for .086" OD Cable
SMP Center Contact Holder
SMP Interface Locator Tool
SMP Right Angle Body Holder
SMP FD Shroud Centering Tool
E
F
G
H
I
J
SMP LD Shroud Centering Tool
SMP SB Shroud Centering Tool
13
