EM78P809N
8-Bit Microcontroller
4.3 Special Purpose Registers
A
(Accumulator)
Internal data transfer, or instruction operand holding.
It cannot be addressed.
CONT (Control Register)
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
WDTO
/INT
WDTP1
WDTP0
WDTE
PSR2
PSR1
PSR0
CONT register is both readable and writable.
Bit 7 ( WDTO ) : WDT output select
WDTO = “0” : Interrupt request
WDTO = “1” : Internal reset
Bit 6 ( /INT ) : Interrupt enable flag
/INT = “0” : masked by DISI or hardware interrupt
/INT = “1” : enabled by ENI/RETI instructions
Bit 5 ~ Bit 4 ( WDTP1 ~ WDTP0 ) : WDT prescaler bits.
WDTP1
WDTP0
Operating Mode
0
0
1
1
0
1
0
1
1:4
1:16
1:64
1:256
Bit 3 ( WDTE ) : WDT enable control.
WDTE = “0” : Disable
WDTE = “1” : Enable
Bit 2 ( PSR2 ) ~ Bit 0 ( PSR0 ) : TCC prescaler bits.
PSR2
PSR1
PSR0
Operating Mode
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
1:2
1:4
1:8
1:16
1:32
1:64
1:128
1:256
Product Specification (V1.0) 07.26.2005
23
(This specification is subject to change without further notice)
