EM78P341N/342N/343N
8-Bit Microprocessor with OTP ROM
9. Read the ADDATA or ADDATA1H and ADDATA1L conversion data registers. If the
ADC input channel changes at this time, the ADDATA, ADDATA1H, and ADDATA1L
values can be cleared to ‘0’.
10. Clear the interrupt flag bit (ADIF)
11. For the next conversion, go to Step 1 or Step 2 as required. At least two Tct is
required before the next acquisition starts.
NOTE
In order to obtain accurate values, it is necessary to avoid any data transition on the I/O
pins during AD conversion.
6.7.6.2 Sample Demo Programs
A. Define a General Register
R_0 == 0
PSW == 3
; Indirect addressing register
; Status register
PORT5 == 5
PORT6 == 6
R_E== 0XE
; Interrupt status register
B. Define a Control Register
IOC50 == 0X5
IOC60 == 0X6
C_INT== 0XF
; Control Register of Port 5
; Control Register of Port 6
; Interrupt Control Register
C. ADC Control Register
ADDATA == 0xB
AISR == 0x08
ADCON == 0x9
; The contents are the results of ADC
; ADC input select register
;
7
6
5
4
3
2
1
0
;VREFS CKR1 CKR0 ADRUN ADPD ADIS2 ADIS1 ADIS0
D. Define Bits in ADCON
ADRUN == 0x4
ADPD == 0x3
; ADC is executed as the bit is set
; Power Mode of ADC
E. Program Starts
ORG 0
; Initial address
JMP INITIAL
;
ORG 0x0C
; Interrupt vector
JMP CLRRE
;
;
;(User program section)
;
;
58 •
Product Specification (V1.0) 12.01.2006
(This specification is subject to change without further notice)
