EC49513A/L
300mA Linear Regulator with Enable
And Fast Discharge Function
Pin Descriptions
Pin Assignment
UFN-6
(Bottom View)
SOT23-5L/TSOT23-5L
(Top View)
Pin#
Pin#
Symbol Function
SOT23-5L/TSOT23-5L UFN-6
Power Input.
Ground Pin.
1
2
3
4
5
1
VIN
5
GND
EN
6
Chip Enable Pin.
No Connection.
2,4
3
NC
VOUT
Voltage Output Pin.
Ordering Information
Package
Part Number
Information
EC49513A-XXXB2G
EC49513L-XXXB2G
EC49513A-XXXFG
EC49513L-XXXFG
EC49513A-XXXT2G
EC49513L-XXXT2G
The XXX character represents Output Voltage. Example: 12=1.2V, 15=1.5V...
SOT23-5L
UFN-6
TSOT23-5
E-CMOS Corp. (www.ecmos.com.tw)
Page 3 of 24
2010/10/29
