XBee®/XBee‐PRO® ZB SMT RF Modules
Specifications
Specifications of the XBee®/XBee‐PRO® ZB SMT RF Module
Specification
Performance
Indoor/Urban Range
Outdoor RF line-of-sight
Range
Transmit Power Output
RF Data Rate
Receiver Sensitivity
Power Requirements
Adjustable Power
Supply Voltage
Operating Current
(Transmit))
Operating Current
(Receive)
Power-down Current
General
Operating Frequency
Band
Dimensions
Weight
Operating Temperature
Antenna Options
Networking & Security
Supported Network
Topologies
Number of Channels
Interface Immunity
Channels
Addressing Options
Interface Options
UART
SPI
Agency Approvals
United States (FCC Part
15.247)
Industry Canada (IC)
Europe (CE)
Australia
FCC ID: MCQ-XBS2C
IC: 1846A-XBS2C
ETSI
Pending
FCC ID: MCQ-XBPS2C
IC: 1846A-XBPS2C
1 Mbps maximum (burst)
5 Mbps maximum (burst)
11 to 26
16 Direct Sequence Channels
Point-to-point, Point-to-multipoint, Peer-to-peer, and Mesh
15 Direct Sequence Channels
DSSS (Direct Sequence Spread Spectrum)
11 to 25
PAN ID and Addresses, Cluster IDs and Endpoints (optional)
ISM 2.4 - 2.5 GHz
0.866” x 1.33” x 0.120” (2.199cm x 3.4cm x 0.305cm)
1.4 oz. (40 g)
-40 to 85º C (industrial)
RF Pad, PCB Antenna, or U.FL Connector
2.1 - 3.6 V
2.2 - 3.6 V for Programmable Version
45mA (+8 dBm, Boost mode)
33mA (+5 dBm, Normal mode)
31mA ( Boost mode)
28mA (Normal mode)
Yes
2.7 - 3.6 V
100mA @ +3.3 V, +18 dBm
31mA
< 1
A
@ 25
o
C
-102 dBm, Boost mode
-100 dBm, Normal mode
Up to 200 ft. (60 m)
Up to 4000 ft. (1200 m)
6.3mW (+8dBm), Boost mode
3.1mW (+5dBm), Normal mode
Channel 26 max power is +3dBm
Up to 300 ft. (90 m)
Up to 2 miles (3200 m)
XBee
XBee-PRO
63mW (+18 dBm, adjustable to 0 dBm)
250,000 bps
-101 dBm
