DM9016
3-port switch with Processor Interface
10.DC and AC Electrical Characteristics
10.1 Absolute Maximum Ratings
Symbol
VCC3
VCCI
AVDD3
AVDDI
VIN
Parameter
3.3V Supply Voltage
1.8V core power supply
Analog power supply 3.3V
Analog power supply 1.8V
DC Input Voltage (VIN)
Storage Temperature range
Ambient Temperature
Min.
3.135
1.71
3.135
1.71
3.135
-65
Max.
3.6
1.95
3.6
1.95
3.6
+150
+70
+260
Unit
V
V
V
V
Conditions
V
TSTG
TA
°C
°C
°C
0
-
Lead Temperature
(TL, soldering, 10 sec.).
LT
Lead-free Device
10.2 Operating Conditions
Symbol
Parameter
Min.
Typ.
Max.
Unit
Conditions
VCC3
VCCI
AVDD3
AVDDI
PD
3.3V Supply Voltage
1.8V core power supply
Analog power supply 3.3V
Analog power supply 1.8V
100BASE-TX
3.135
1.71
3.135
1.71
-
3.30
1.80
3.30
1.80
230
70
3.465
1.89
3.465
1.89
-
V
V
V
V
mA
mA
mA
mA
1.8V only
3.3V only
TX idle, 1.8V only
50% utilization,
1.8V only
(Power
Dissipation)
-
-
10BASE-TX
140
250
360
mA
100% utilization,
1.8V only
30
170
40
mA
mA
mA
3.3V only
1.8V only
3.3V only
Auto-negotiation or cable off
78
Preliminary datasheet
DM9016-13-DS-P01
March 26, 2009
