PSoC® 3: CY8C32 Family
Data Sheet
Figure 13-1. 48-pin (300 mil) SSOP Package Outline
.020
24
1
0.395
0.420
0.292
0.299
DIMENSIONS IN INCHES MIN.
MAX.
25
48
0.620
0.630
0.005
0.010
SEATING PLANE
.010
0.088
0.092
0.095
0.110
GAUGE PLANE
0.024
0.040
0.004
0.025
BSC
0°-8°
0.008
0.016
0.008
51-85061-*D
0.0135
Figure 13-2. 48-pin QFN Package Outline
SIDE VIEW
TOP VIEW
BOTTOM VIEW
1.00 MAX.
0.05 MAX.
7.00±0.10
5.6±0.10
PIN 1 ID
0.23±0.05
0.20 REF.
48
37
37
48
36
36
1
1
PIN 1 DOT
LASER MARK
SOLDERABLE
EXPOSED
PAD
7.00±0.10
5.55 REF
5.6±0.10
12
25
12
25
0.40±0.10
24
13
13
24
0.50±0.10
5.55 REF
0.08
C
NOTES:
1. HATCH AREA IS SOLDERABLE EXPOSED METAL.
2. REFERENCE JEDEC#: MO-220
3. PACKAGE WEIGHT: 0.13g
4. ALL DIMENSIONS ARE IN MM [MIN/MAX]
5. PACKAGE CODE
001- 45616 *B
PART #
LT48D
DESCRIPTION
LEAD FREE
Document Number: 001-56955 Rev. *J
Page 110 of 119
