5. Development Tool Selection
This chapter presents the development tools available for all current PSoC device families including the CY8C21x34 family.
5.1
Software
5.2
Development Kits
All development kits can be purchased from the Cypress Online
Store.
5.1.1
PSoC Designer™
At the core of the PSoC development software suite is PSoC
Designer. Utilized by thousands of PSoC developers, this
robust software has been facilitating PSoC designs for half a
decade. PSoC Designer is available free of charge at http://
www.cypress.com under DESIGN RESOURCES >> Software
and Drivers.
5.2.1
CY3215-DK Basic Development Kit
The CY3215-DK is for prototyping and development with PSoC
Designer. This kit supports in-circuit emulation and the software
interface allows users to run, halt, and single step the processor
and view the content of specific memory locations. Advance
emulation features also supported through PSoC Designer. The
kit includes:
5.1.2
PSoC Express™
■ PSoC Designer Software CD
As the newest addition to the PSoC development software
suite, PSoC Express is the first visual embedded system design
tool that allows a user to create an entire PSoC project and
generate a schematic, BOM, and data sheet without writing a
single line of code. Users work directly with application objects
such as LEDs, switches, sensors, and fans. PSoC Express is
available free of charge at http://www.cypress.com/psocex-
press.
■ ICE-Cube In-Circuit Emulator
■ ICE Flex-Pod for CY8C29x66 Family
■ Cat-5 Adapter
■ Mini-Eval Programming Board
■ 110 ~ 240V Power Supply, Euro-Plug Adapter
■ iMAGEcraft C Compiler (Registration Required)
■ ISSP Cable
5.1.3
PSoC Programmer
■ USB 2.0 Cable and Blue Cat-5 Cable
■ 2 CY8C29466-24PXI 28-PDIP Chip Samples
Flexible enough to be used on the bench in development, yet
suitable for factory programming, PSoC Programmer works
either as a standalone programming application or it can oper-
ate directly from PSoC Designer or PSoC Express. PSoC Pro-
grammer software is compatible with both PSoC ICE-Cube In-
Circuit Emulator and PSoC MiniProg. PSoC programmer is
available free ofcharge at http://www.cypress.com/psocpro-
grammer.
5.1.4
CY3202-C iMAGEcraft C Compiler
CY3202 is the optional upgrade to PSoC Designer that enables
the iMAGEcraft C compiler. It can be purchased from the
Cypress Online Store. At http://www.cypress.com, click the
Online Store shopping cart icon at the bottom of the web page,
and click PSoC (Programmable System-on-Chip) to view a cur-
rent list of available items..
January 12, 2007
Document No. 38-12025 Rev. *K
37
