CY7C68300B/CY7C68301B
CY7C68320/CY7C68321
Table 8-6. EEPROM Organization (continued)
EEPROM
Required Suggested
Contents Contents
Address
Field Name
Field Description
Unicode character LSB.
0X100
bString
bString
bString
bString
“A” 0x41
0x00
0X101
Unicode character MSB.
Unicode character LSB.
Unicode character MSB.
0X102
“B” 0x42
0x00
0X103
Identify Device String (Note: This is not a Unicode string. It is the ASCII string returned by the device in the Identify Device
information. It is a fixed length (24 bytes). Changing this string may cause CD authoring software to incorrectly identify the device.)
0X104
0X105
0X106
0X107
0X108
0X109
0X10A
0X10B
0X10C
0X10D
0X10E
0X10F
0X110
0X111
0X112
0X113
0X114
0X115
0X116
0X117
0X118
0X119
0X11A
0X11B
Device name byte 1
Device name byte 2
Device name byte 3
Device name byte 4
Device name byte 5
Device name byte 6
Device name byte 7
Device name byte 8
Device name byte 9
Device name byte 10
Device name byte 11
Device name byte 12
Device name byte 13
Device name byte 14
Device name byte 15
Device name byte 16
Device name byte 17
Device name byte 18
Device name byte 19
Device name byte 20
Device name byte 21
Device name byte 22
Device name byte 23
Device name byte 24
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
ASCII Character
“C” 0x43
“y” 0x79
“p” 0x70
“r” 0x72
“e” 0x65
“s” 0x73
“s” 0x73
“ “ 0x20
“C” 0x43
“u” 0x75
“s” 0x73
“t” 0x74
“o” 0x6f
“m” 0x6d
“ ” 0x20
“N“ 0x4e
“a“ 0x61
“m“ 0x6d
“e“ 0x65
“ ” 0x20
“L” 0x4c
“U” 0x55
“N” 0x4e
“0” 0x30
0xFF
0x11C to Unused ROM Space
0x1FF
Amount of unused ROM space will vary depending on
strings.
Note: More than 0X100 bytes of configuration are shown for example only. AT2LP only supports 0X100 total bytes.
