CY7C68013A, CY7C68014A
CY7C68015A, CY7C68016A
Figure 2-2. Reset Timing Plots
RESET#
RESET#
VIL
VIL
3.3V
3.0V
3.3V
VCC
VCC
0V
0V
TRESET
TRESET
Power on Reset
Powered Reset
Table 2-1. Reset Timing Values
2.10 Program/Data RAM
2.10.1 Size
Condition
TRESET
Power on reset with crystal
5 ms
The FX2LP has 16 KBytes of internal program/data RAM, where
PSEN#/RD# signals are internally ORed to enable the 8051 to
access it as both program and data memory. No USB control
registers appear in this space.
Power on reset with external
clock
200 s + Clock stability time
Powered Reset
200 s
Two memory maps are shown in the following diagrams:
Figure 2-3 on page 9 shows the Internal Code Memory, EA = 0
Figure 2-4 on page 10 shows the External Code Memory, EA = 1.
2.9.2 Wakeup Pins
The 8051 puts itself and the rest of the chip into a power down
mode by setting PCON.0 = 1. This stops the oscillator and PLL.
When WAKEUP is asserted by external logic the oscillator
restarts after the PLL stabilizes, and the 8051 receives a wakeup
interrupt. This applies whether or not FX2LP is connected to the
USB.
2.10.2 Internal Code Memory, EA = 0
This mode implements the internal 16 KByte block of RAM
(starting at 0) as combined code and data memory. When
external RAM or ROM is added, the external read and write
strobes are suppressed for memory spaces that exist inside the
chip. This enables the user to connect a 64 KByte memory
without requiring address decodes to keep clear of internal
memory spaces.
The FX2LP exits the power down (USB suspend) state using one
of the following methods:
■ USB bus activity (if D+/D– lines are left floating, noise on these
lines may indicate activity to the FX2LP and initiate a wakeup)
Only the internal 16 KBytes and scratch pad 0.5 KBytes RAM
spaces have the following access:
■ External logic asserts the WAKEUP pin
■ External logic asserts the PA3/WU2 pin
■ USB download
■ USB upload
The second wakeup pin, WU2, can also be configured as a
general purpose I/O pin. This enables a simple external R-C
network to be used as a periodic wakeup source. WAKEUP is by
default active LOW.
■ Setup data pointer
■ I2C interface boot load.
2.10.3 External Code Memory, EA = 1
The bottom 16 KBytes of program memory is external and
therefore the bottom 16 KBytes of internal RAM is accessible
only as a data memory.
Document #: 38-08032 Rev. *V
Page 8 of 66
