CY7C63411/12/13

CY7C63511/12/13

CY7C63612/13

1.0

Features

• Low-cost solution for low-speed applications such as mice, gamepads, keyboards, joystick and others

• USB Specification Compliance

— Conforms to USB Specification, Versions 1.1 and 2.0

— Conforms to USB HID Specification, Version 1.1

— Supports 1 device address and 3 data endpoints

— Integrated USB transceiver

• 8-bit RISC microcontroller

— Harvard architecture

— 6-MHz external ceramic resonator

— 12-MHz internal CPU clock

• Internal memory

— 256 bytes of RAM

— 4 Kbytes of EPROM (CY7C63411, CY7C63511)

— 6 Kbytes of EPROM (CY7C63412, CY7C63512, CY7C63612)

— 8 Kbytes of EPROM (CY7C63413, CY7C63513, CY7C63613)

• Interface can auto-configure to operate as PS2 or USB

• I/O port

— The CY7634XX/5XX have 24 General Purpose I/O (GPIO) pins (Port 0 to 2) capable of sinking 7 mA per pin (typical)

— The CY7C636XX have 12 General-Purpose I/O (GPIO) pins (Port 0 to 2) capable of sinking 7 mA per pin (typical)

— The CY7C634XX/5XX have eight GPIO pins (Port 3) capable of sinking 12 mA per pin (typical) which can drive LEDs

— The CY7C636XX have four GPIO pins (Port 3) capable of sinking 12 mA per pin (typical) which can drive LEDs

— Higher current drive is available by connecting multiple GPIO pins together to drive a common output

— Each GPIO port can be configured as inputs with internal pull-ups or open drain outputs or traditional CMOS outputs

— The CY7C635XX has an additional eight I/O pins on a DAC port which has programmable current sink outputs

•

•

•

•

•

•

•

•

•

•

— Maskable interrupts on all I/O pins

12-bit free-running timer with one microsecond clock ticks

Watch Dog Timer (WDT)

Internal Power-On Reset (POR)

Improved output drivers to reduce EMI

Operating voltage from 4.0V to 5.5V DC

Operating temperature from 0 to 70 degrees Celsius

CY7C634XX available in 40-pin PDIP, 48-pin SSOP for production

CY7C635XX available in 48-pin SSOP packages for production

CY7C636XX available in 24-pin SOIC packages for production

Industry-standard programmer support
