13. DC Characteristics
Note: Values in this data sheet are design goals and are subject to change based on the results of device characterization.
13.1 Absolute Maximum Ratings
Caution! The absolute maximum ratings in Table 21 indicate levels where permanent damage to the device can occur, even if these
limits are exceeded for only a brief duration. Functional operation is not guaranteed under these conditions. Operation at absolute
maximum conditions for extended periods can adversely affect long-term reliability of the device.
Table 21. Absolute Maximum Ratings
Rating
DC supply for VBATa and PA driver supplyb
DC supply voltage for digital I/O
DC supply voltage for RF switch I/Os
DC input supply voltage for CLDO and LNLDO
DC supply voltage for RF analog
DC supply voltage for core
Symbol
Value
–0.5 to +6.0
Unit
VBAT
V
V
V
V
V
V
V
V
V
°C
VDDIO
–0.5 to 3.9
–0.5 to 3.9
–0.5 to 1.575
–0.5 to 1.32
–0.5 to 1.32
–0.5 to 3.63
–0.5
VDDIO_RF
–
VDDRF
VDDC
–
WRF_TCXO_VDD
Maximum undershoot voltage for I/Oc
Maximum overshoot voltage for I/Oc
Maximum junction temperature
Vundershoot
Vovershoot
Tj
VDDIO + 0.5
125
a. VBAT is the main power supply of the chip.
b. Voltage transients up to 6.0V for up to 10 seconds, cumulative duration over the lifetime of the device, are allowed. Voltage transients as high
as 5.5V for up to 250 seconds, cumulative duration over the lifetime of the device, are allowed.
c. Duration not to exceed 25% of the duty cycle.
13.2 Environmental Ratings
The environmental ratings are shown in Table 22.
Table 22. Environmental Ratings
Characteristic
Ambient temperature (TA)
Value
0 to +60
Units
Conditions/Comments
Functional operationa
°C
°C
%
Storage temperature
Relative humidity
–40 to +125
Less than 60
Less than 85
–
Storage
Operation
%
a. Functionality is guaranteed but specifications require derating at extreme temperatures; see the specification tables for details.
