V.22 bis Modem with AT Commands
CMX866
Figure 2b Recommended Power Supply Connections and De-coupling
ANALOGUE
DIGITAL
C3, C6
C7
L2
100nF
10uF
100nH
C4
C5
L1
100nF
10uF
100nH
(optional, see note)
(optional, see note)
Note: The inductors L1 and L2 and the electrolytic capacitor C7 can be omitted without significantly
degrading the system performance.
ã 2004 CML Microsystems Plc
7
D/866/4
