7.1.1 Passive Input Filter
The passive filter implementation shown in Figure 28 will attenuate any noise energy at
6.144 MHz but will not provide optimum source impedance for the ADC modulators. Full analog
performance will therefore not be realized using a passive filter. Figure 28 illustrates the unity
gain, passive input filter solution. In this topology the distortion performance is affected, but the
dynamic range performance is not limited.
ADC1-2
10 µF
150 Ω
AIN1+,2+,3+,4+
2700 pF
C0G
100 kΩ
AIN1-,2-,3-,4-
4.7 µF
ADC3
10 µF
150 Ω
AIN5A,6A
2700 pF
C0G
100 kΩ
10 µF
150 Ω
AIN5B,6B
2700 pF
C0G
100 kΩ
Figure 28. Passive Input Filter
7.1.2 Passive Input Filter w/Attenuation
Some applications may require signal attenuation prior to the ADC. The full-scale input voltage
will scale with the analog power supply voltage. For VA = 5.0 V, the full-scale input voltage is
approximately 2.8 Vpp, or 1 Vrms (most consumer audio line-level outputs range from 1.5 to
2 Vrms).
Figure 29 shows a passive input filter with 6 dB of signal attenuation. Due to the relatively high
input impedance on the analog inputs, the full distortion performance cannot be realized. Also,
the resistor divider circuit will determine the input impedance into the input filter. In the circuit
shown in Figure 29, the input impedance is approximately 5 kΩ. By doubling the resistor values,
the input impedance will increase to 10 kΩ. However, in this case the distortion performance will
drop due to the increase in series resistance on the analog inputs.
