LH0032 / LH0032C
CORPORATION
ABSOLUTE MAXIMUM RATINGS
Supply Voltage, VS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±18V
Input Voltage, VIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±VS
Differential Input Voltage . . . . . . . . . . . . . . . . . . ±30V or± 2VS
Power Dissipation, PD
Operating Temperature Range, TA
LH0032G . . . . . . . . . . . . . . . . . . . . . . . . . -55oC to +125oC
LH0032CG . . . . . . . . . . . . . . . . . . . . . . . . . -25oC to +85oC
Operating Junction Temperature, TJ . . . . . . . . . . . . . . 175oC
Storage Temperature Range . . . . . . . . . . . . -65oC to +150oC
Lead Temp. (Soldering, 10 seconds). . . . . . . . . . . . . . 300oC
TA = 25oC. . . . . . . . . . . . . 1.5W, derate 100oC/W to 125oC
TC = 25oC. . . . . . . . . . . . . 2.2W, derate 70oC/W to 125oC
DC ELECTRICAL CHARACTERISTICS VS = ±15V, TMIN ≤ TA ≤ TMAX unless otherwise noted (Note 1) (TA = Tj)
LH0032
TYP
2
LH0032C
SYMBOL
PARAMETER
UNITS
TEST CONDITIONS
MIN
MAX
MIN
TYP
MAX
5
10
2
15
20
VOS
Input Offset Voltage
mV
TA = TJ = 25oC (Note 3)
∆VOS/∆T
Average Offset Voltage Drift
15
50
15
50
µV/oC
(Note 4)
25
250
25
50
500
5
pA
pA
nA
TJ = 25oC (Note 2)
VIN = 0
IOS
Input Offset Current
T
A = 25oC (Note 3)
100
1
50
500
5
15
pA
nA
nA
TJ = 25oC (Note 2)
T
A = 25oC (Note 3)
IB
Input Bias Current
Input Voltage Range
VINCM
±10
50
±12
60
±10
50
±12
60
V
Note 6
Common Mode Rejection
Ratio
CMRR
dB
dB
∆VIN = ±10V
60
70
60
70
VO = ±10V,
TJ = 25oC
f = 1kHz
RL = 1kΩ
(Note 7)
AVOL
Open-Loop Voltage Gain
57
57
VO
IS
Output Voltage Swing
Power Supply Current
±10
±13.5
±10
±13
V
RL = 1kΩ
T
A = 25oC,
O = 0 (Note 3)
18
20
20
22
mA
I
Power Supply Rejection
Ratio
∆VS = 10V
(±5 to ±15V)
PSRR
50
60
50
60
dB
