ACPI Aware O/S:
This item is the Advanced Configuration and Power Interface
(ACPI) function switch. The available options are Yes, and No.
ACPI Standby State:
This item serves as the switch setting of STR (S3) or POS (S1)
function. Configuration options are S3/STR, and S1/POS.
Power Management/APM:
Set this option to Enabled to switch on the APM (Advanced Power
Management). The available options are Enabled, and Disabled.
Standby Time Out:
This option specifies the length of system inactivity period while in
the Standby state. When this length of time expires, the computer
enters Suspend power state.
ꢂ
ꢂ
Restore on AC/Power Loss:
This field registers the last power supply unit attached to your
system. If an ATX power was last used before changing to AT
power supply, setting this field to Last State (default) will NOT
make the AT power supply function properly on your next boot up
process. Setting this field to Power On auto-detects the power
supply installed each time you boot up.
Wake Up On Ring:
An input signal on the serial Ring Indicator (RI) line (in other
words, an incoming call on the modem) awakens the system from
a soft off state. The available choices are Enabled, Disabled.
ꢂ
ꢂ
ꢂ
ꢂ
Wake Up On Lan
An input signal on the local area network (LAN) awakens the
system from a soft off state.
Wake Up On PME
A PME# detected resumes or wakes the system from a Soft Off
state.
Resume By Alarm
When this option is set enabled, system will according to you set
time then wakeup from soft off mode.
Alarm Date/Hour/Minute/Second
You can set these fields to specify the alarm settings of your
system.
43
