4.10 Hardware Monitor Setup
AMIBIOS SETUP – HARDWARE MONITOR SETUP
(C)2001 American Megatrends, Inc. All Rights Reserved
*** System Hardware Monitor ***
Chassis Intrusion
TSENS1 Temperature
CPU Fan Speed
Chassis Fan Speed
Vcore
Available Options:
` Disabled
Enabled
Disabled
Reset
+ 2.500V
+3.300V
+5.000V
+12.000V
ꢄꢅ
ESC:Exit
:Sel
PgUp/PgDn: Modify
F1:Help
F2/F3:Color
ꢂ
System Hardware Monitor:
This field determines which component will detect the CPU
temperature. If your board comes with a provision for a thermal
connector, you may set this field as Thermistor. Otherwise, please
configure it as CPU (also default setting).
ꢀ
ꢀ
TSENS1 Temperature:
This read-only field displays the current CPU temperature as
part of the hardware monitoring feature of your board.
Current CPU/FAN Speeds:
These fields display the current speed of up to CPU, chassis
(system) and Power supply fans, if your computer contains a
monitoring system.
ꢀ
+5V/+12V/+3.3V/+2.5V:
Once the hardware monitoring IC detects the current
voltages of voltage regulators and power supply unit, it shows
the values on these fields for read-only purposes.
47
