BL9110
1A Low Dropout, Low Quiescent Current
High PSRR CMOS Linear Regulator
SOT-223-3
Devices per reel 2500
Package
SOT-223
Unit
mm
Package specification：
MIN NOM MAX
.
A
1.50 1.65 1.80
A1 0.02 0.06 0.10
A2 1.45 1.60 1.75
A3 0.80 0.90 1.00
b
0.67
0.66 0.71 0.75
2.96 3.09
2.95 3.00 3.05
0.30 0.35
0.29 0.30 0.31
6.35 7.05
-
0.80
b1
b2
b3
c
c1
D
-
-
-
D1 6.30 6.50 6.70
6.80 7.00 7.20
E1 3.40 3.50 3.60
E
e
e1
L
L1
L2
θ
2.30BSC
4.60BSC
0.80 1.00 1.20
1.75REF
0.25BSC
0°
-
8°
θ 1 10° 12° 14°
PPMIC BU
BL9110 Rev 2.0
04/2016
www.belling.com.cn
